Light Symphony 4-channel Wireless Receivers
Within the Light Symphony range there are two separate 4-channel receiver options to choose from.
The Light Symphony 4-channel wireless receivers (dimming) are not only compatible with dimmable lighting systems and dimmable pond pumps, but are also compatible with RGB and RGB/W colour changing LEDs, as well as the relevant drivers (please note it is not possible to mix RGB and RGB/W LEDs). All outputs can be set to dimming, which provides a ‘soft on/soft off’ feature for a pleasing visual effect and increased lamp life for your fittings. The maximum wattage on this model is 500w per line.
The Light Symphony 4-channel mini wireless receiver (non-dimming) also contains four switched outputs, although without the dimming function and RGB/W compatibility. This makes them more cost effective and also reduces the physical size of the receiver. This simpler system also enables a higher maximum wattage at 700w per line.
Once wired in and powered, any switches or fobs can be quickly and easily programmed to any of the outputs. It’s quickly configurable as a simple switch, group (zone) or scene controller, with 29 memories and a master on/off. They can be used with key-fobs, timers, PIRs, the Light Symphony smart phone App and even Alexa via the Light Symphony Smart timer with iPort. The Smart timer also allows for automatic switching of lights based on user programmed settings or based on the astronomical clock that tracks dusk and dawn times throughout the year.
The Light Symphony 4-channel wireless receivers (dimming) are not only compatible with dimmable lighting systems and dimmable pond pumps, but are also compatible with RGB and RGB/W colour changing LEDs, as well as the relevant drivers (please note it is not possible to mix RGB and RGB/W LEDs). All outputs can be set to dimming, which provides a ‘soft on/soft off’ feature for a pleasing visual effect and increased lamp life for your fittings. The maximum wattage on this model is 500w per line.
The Light Symphony 4-channel mini wireless receiver (non-dimming) also contains four switched outputs, although without the dimming function and RGB/W compatibility. This makes them more cost effective and also reduces the physical size of the receiver. This simpler system also enables a higher maximum wattage at 700w per line.
Once wired in and powered, any switches or fobs can be quickly and easily programmed to any of the outputs. It’s quickly configurable as a simple switch, group (zone) or scene controller, with 29 memories and a master on/off. They can be used with key-fobs, timers, PIRs, the Light Symphony smart phone App and even Alexa via the Light Symphony Smart timer with iPort. The Smart timer also allows for automatic switching of lights based on user programmed settings or based on the astronomical clock that tracks dusk and dawn times throughout the year.
Specification
Light Symphony 4-channel wireless receiver (dimming) - 1km range
Product Code: RML3244
Dimensions: length 290mm; depth 100mm; height 210mm; height w/ antenna 290mm (approx.); each output is dimmable and rated at 500w
Product Code: RML3244
Dimensions: length 290mm; depth 100mm; height 210mm; height w/ antenna 290mm (approx.); each output is dimmable and rated at 500w
Light Symphony 4-channel mini wireless receiver (non-dimming) - 1km range
Product Code: RML3242
Dimensions: length 225mm; depth 85mm; height 150mm; height w/ antenna 185mm (approx.); each output is rated at 700w
Product Code: RML3242
Dimensions: length 225mm; depth 85mm; height 150mm; height w/ antenna 185mm (approx.); each output is rated at 700w
