Techline Professional In-line Drip Pipe

Techline Professional In-line Drip Pipe

Techline is the world's leading irrigation drip pipe, beating all similar products in terms of reliability, longevity and quality. Techline is often the go-to drip line for the industry professional thanks to its wide array of features:

  • Pressure Compensating - ensures that each individual dripper emits the same amount of water across a wide pressure range (1 bar to 4 bar).
  • Self-cleaning - debris is continuously flushed from the dripper, preventing blockages throughout the water cycle.
  • Flexible - designed with a bending radius of 18cm, allowing 'snaking' of the pipe for curved beds, as well as for creating rings around trees or shrubs.
  • Anti-siphon Drippers - mechanism within the dripper prevents sediment, debris or other contaminants from being drawn into the dripper.
  • Installation Options - can be installed on the surface, or sub-surface (covered with mulch) to reduce evaporation.
  • UV Resistance - ensures longevity if installed on the surface due to high resistance to heat and direct sunlight.

Specification

Area of Coverage 30m² per 100m of Techline (approx.)
Bar Pressure 1- 4 Bar
Flow Rate 2.3 l/hour per dripper
Installation Type Surface or sub-surface
Max. Run Length 111 metres @ 4.0 Bar
Max. Run Length 72 metres @ 1.5 Bar
Size of Pipe/ Fitting 14mm/16mm - In-line Drip Pipe
Spacing Dripper every 300mm of pipe (3.33 drippers per m)
Techline professional in-line drip pipe - 14mm (ID) - 50m roll
Product Code: TCP1634
14mm inside diameter; 16mm outside diameter; each 50m roll of Techline professional in-line drip pipe will cover an area approx 15m².
Techline professional in-line drip pipe - 14mm (ID) - 100m roll
Product Code: TCP1636
14mm inside diameter; 16mm outside diameter; each 100m roll of Techline professional in-line drip pipe will cover an area approx 30m².
